15A Advanced Micro-Crystal Chemical crystallography Beamline

With a highly brilliance micro-focus X-ray beam, a high precision kappa-geometry goniometer and a large-area detector, 15A aims to determine 3D crystal structures from micro-scale single crystals and non-ambient conditions.

UNIQUE FEATURES

  • Micro-size chemical crystal structural determination
  • Non-ambient crystal structural characterization:

     - photo-excitation,

     - high pressure (Up to 20 GPa )

     - ultra low temperature (15 K )

  • Pink beam Laue diffraction
  • Sub-nanosecond time-resolved Single crystal diffraction


CORE EXPERIMENTAL TECHNIQUES

  • Single crystal X-ray diffraction
  • Laue diffraction
  • Sub-nanosecond time-resolved structural information
  • Microbeam diffraction
  • Non-ambient technique


SCIENTIFIC OPPORTUNITIES

  • Challenging difficult crystal
  • Metastable state crystallography
  • Photo-induced crystallography
  • Non-ambient conditions on crystal Time-resolved dynamic structure


BEAMLINE SPECIFICATIONS

  • 2 m CUT15 (Tapered  Cryogenic Undulator) source
  • Energy range: 8 – 35 keV
  • Coupled DMM/DCM for pink beam with flux~ 1 × 1015 s-1  (bandwidth 3 – 5 %) or monochromatic beam with flux~ 1 × 1013 s-1, energy resolution ΔE/E = 1.65 × 10-4 at 8 keV.
  • Beam size: ES0 ~ 200 (H) × 200 (V) μm2, adjustable by slits
    ES1 ~ 70 (H) × 70 (V) – 2 (H) × 2 (V) μm2, adjustable
  • Source divergences: < 50 (H) × 25 (V) μrad2
  • High precision kappa-geometry micro-diffractometer
  • Beamline automation



BEAMLINE LAYOUT
